SQLite as a Vector Database

Implementing Similarity Search and ML Embeddings

SQLite is not a vector database. However, it can store embeddings and perform similarity search reliably for small to medium datasets.

This article shows how to use SQLite as a simple, real vector store using:

• Proper ML embeddings

• Cosine similarity

• Plain SQL

• No external services

The goal is practical execution, not theory.

When SQLite Makes Sense for Vector Search

SQLite works well when:

• Your data fits on a single machine

• You want zero infrastructure

• You already use SQLite

• You need predictable, inspectable behavior

SQLite does not make sense when:

• You need ANN indexes (HNSW, IVF)

• You are working at million+ vector scale

• You require very low latency at high concurrency

This approach targets prototypes, internal tools, embedded apps, and small semantic search systems.

What Embeddings Are

An embedding converts text into a numeric vector such that similar text produces similar vectors.

Typical text embedding sizes:

• 384 dimensions

• 768 dimensions

• 1536 dimensions

We will use cosine similarity, which is standard for text embeddings.

Step 1: Install Requirements

You need:

• Python 3.9+

• numpy

• sentence-transformers

pip install numpy sentence-transformers

This blog uses a real embedding model:
all-MiniLM-L6-v2

Step 2: Database Schema

SQLite has no vector type.
Vectors are stored as BLOBs.

CREATE TABLE embeddings (
  id INTEGER PRIMARY KEY,
  content TEXT NOT NULL,
  embedding BLOB NOT NULL
);

Why BLOBs

• Compact

• Fast

• No JSON parsing

• Direct float32 deserialization

This is the correct choice for SQLite.

Step 3: Create the Database and Table

import sqlite3

conn = sqlite3.connect("vectors.db")
conn.execute("PRAGMA journal_mode=WAL;")

conn.execute("""
CREATE TABLE IF NOT EXISTS embeddings (
  id INTEGER PRIMARY KEY,
  content TEXT NOT NULL,
  embedding BLOB NOT NULL
);
""")

conn.commit()

Step 4: Generate Real Embeddings

This uses a real ML model.
The output vectors are meaningful and usable.

from sentence_transformers import SentenceTransformer
import numpy as np

model = SentenceTransformer("all-MiniLM-L6-v2")

def embed_text(text: str) -> np.ndarray:
    vector = model.encode([text], normalize_embeddings=True)
    return np.asarray(vector[0], dtype=np.float32)

Important:

• normalize_embeddings=True ensures cosine similarity works correctly

• Output is always float32

Step 5: Store Embeddings in SQLite

documents = [
    "SQLite WAL mode improves concurrency",
    "Embeddings represent text as vectors",
    "Cosine similarity is used for semantic search",
    "SQLite can store vectors as BLOBs",
    "Approximate nearest neighbor search improves scale"
]

for doc in documents:
    vec = embed_text(doc)
    conn.execute(
        "INSERT INTO embeddings (content, embedding) VALUES (?, ?)",
        (doc, vec.tobytes())
    )

conn.commit()

All vectors must have the same dimension.

Step 6: Register Cosine Similarity in SQLite

SQLite does not include vector math.
We add it from Python.

import math
import numpy as np

def cosine_similarity(blob1, blob2):
    v1 = np.frombuffer(blob1, dtype=np.float32)
    v2 = np.frombuffer(blob2, dtype=np.float32)

    dot = float(np.dot(v1, v2))
    n1 = float(np.dot(v1, v1))
    n2 = float(np.dot(v2, v2))

    if n1 == 0.0 or n2 == 0.0:
        return 0.0

    return dot / (math.sqrt(n1) * math.sqrt(n2))

conn.create_function("cosine_similarity", 2, cosine_similarity)

This enables similarity search directly in SQL.

Step 7: Perform Similarity Search

Embed the query, then rank results.

query = "How do I store embeddings in SQLite?"
query_vec = embed_text(query).tobytes()

rows = conn.execute("""
SELECT content,
       cosine_similarity(embedding, ?) AS score
FROM embeddings
ORDER BY score DESC
LIMIT 5;
""", (query_vec,)).fetchall()

Print results:

for rank, (content, score) in enumerate(rows, start=1):
    print(f"{rank}. score={score:.4f} | {content}")

This performs a full table scan.
That is expected.

Performance Characteristics

This approach is acceptable when:

• Dataset is up to tens of thousands of vectors

• Reads dominate writes

• You enable WAL mode

Key points:

• SQLite evaluates similarity row by row

• There is no vector index

• Latency grows linearly with row count

Approximate Nearest Neighbor in SQLite

SQLite does not support ANN natively.

Practical workarounds:

• Filter rows by metadata before similarity search

• Partition data into smaller tables

• Reduce vector dimensionality

• Cache frequent queries

These reduce comparisons, not complexity.

When to Move Away from SQLite

You should migrate when:

• Query latency becomes unacceptable

• Dataset grows beyond memory limits

• ANN indexing becomes a requirement

SQLite is a starting point, not a dead end.

Final Notes

SQLite can be used as a vector database when used intentionally.

This setup:

• Uses real embeddings

• Produces meaningful similarity results

• Requires no infrastructure

• Is easy to debug and inspect

Within its limits, this approach is practical, reliable, and effective.
